Liniotech 3.6kW Off-Grid Inverter | 3600EHV-48V All in One | 3600W Output | 4000W PV Input 90-450V

Walmart

Liniotech 3.6kW Off-Grid Inverter | 3600EHV-48V All in One | 3600W Output | 4000W PV Input 90-450V

$499.00

  • Max open-circuit voltage of 300VDC
  • 4000W max usable solar panel PV array power when combining 2 strings with a branch connector
  • 80A max PV string current
  • Capable of charging a 5.12kWh Liniotech battery in ~2 hour @ 80A
  • Recommended operating usage: 80A total or 30A per battery to maintain battery lifespan
  • 48-60VDC charging voltage (default 56Vdc)
  • PV array DC disconnect breaker
  • Built-in battery breaker for added protection
  • 94% max charge controller efficiency
  • Less than 25W self-consumption
  • The MPPT charger is able to communicate with Liniotech batteries when operating with non-Liniotech compatible inverters via its USB/RS485 (Wifi/GPRS) BMS port.
  • This 3.6kw Inverter can run without Battery
  • Model (DFUS-)3.6KW6.5KW12KWParallel Mode (Function Reserved)Allow Quantity1 - 6Mains ModeNominal Input Voltage120Vac±5%120(L1/N,L2/N)/240Vac(L1/L2)Input Phase Voltage Range(90Vac - 140Vac)±2%(85Vac~140Vac)±2%Frequency50Hz /60Hz (Auto Detection)Frequency Range47±0.3Hz~55±0.3Hz(50Hz);57±0.3Hz~65±0.3Hz(60Hz);Max. Efficiency>95%Conversion Time (Bypass And Inverter)10ms(Typical)Max.Bypass Phase Overload Current40A63A2P,63A/63A(L1/L2)Inverter ModeOutput Voltage WaveformPure Sine WaveNominal Output Power (VA) / (W)3600VA/3600W6500VA/6500WSplit Phase:12000VA/12000W Single Phase: 7200VA/7200WPower Factor1Nominal Output Voltage (VAC)120Vac120Vac (L1/N, L2/N)/240Vac(L1/L2)Output Frequency Range(H2)50Hz±0.3Hz/60Hz±0.3HzMax.Efficiency>91%Overload Protection(102% < load <125%) ± 10%: report error and turn off the output after 5 minutes; (125% < load < 150%) ± 10%: report error and turn off the output after 10 seconds; Load >150% ± 5%: report error and turn off the output after 5 seconds;(110% < load < 125%) ± 5% Load >125% ± 5%Peak Power72000VA12000VASplt phase: 18000VA Single phase:18000VALoaded Motor Capability2HP5HP6HPNominal Battery Input Veltage48V (Minimum starting voltage 44V)Battery Voltage Range40.0Vdc~60Vdc±0.5Vdc40.0Vdc~60Vdc±0.6Vdc (Undervoltage alarm/shutdown voltage/ overvoltage alarm/overvoltage recovery... settable on LCD screen)Save Power ModeLoad≤25W Enter Power - Saving ModeMains ChargeBattery TypeLead acid or lithium batterMax.Charge Current(Configurable)40A120A160ACharge Voltage Range40 - 60VdcSolar ChargeMax. PV Open Crouit Voltage300Vdc300VdcSOOVSCPV Operate Volage Range80Vdc - 300Vdc80vdc - 300vdc90vdc - 500vdcMPPT Voltage Range90Vdc - 260Vdc90vdc - 250vdc90Vdc - 450vdcBattery Voltage Range40 - 60Vdc40 - 60Vdc40 - 60VdcMax.PV Input Power/Current4000W/22A4500W×2/22A×26000W×2/22A×2Charge Current Range (Configurable)0 - 80A0 - 150A220AMax.Hybrid Charge Current (PV + AC)Max.Hybrid Charge Current (Configurable)0 - 80A0 - 150A0 - 220ACertificationSafety CertificationCECIEC62109 - 1.2UL STD.1741EMC Certification LevelEN61000.C2FCC part15,CLASS BOperate Temperature Range-15℃ to 55℃-10℃Cto 55°C(>45℃C derating)Storage Temperature Range-25℃~60℃Humidity Range5% to 95% (Three anti - paint protection)5% to 95% (Conformal coating protection)Noise≤60dBCoolingForced air cooling. Dual intelligent speed regulating fansCommunicateUSB/RS485/WIFI/GPRS/ Dry node controlDimensions(L"W*Dmm)415*280*100550*365*130620*450*132Weight (NG)7.82023.8
  • Volts: 48 V
  • Brand: LINIOTECH
  • Has written warranty: No
  • Weight: 7.8 lbs
  • Model: MPPT100-48HV
Tienda:
Walmart
Marca:
LINIOTECH
Modelo:
MPPT100-48HV
Fabricante:
LINIOTECH
Clasificación:
Power Inverters
